Turbo cleaning


  • Please log in to reply
8 replies to this topic

#1 davemcd63

davemcd63

    Briskodian

  • Members
  • Pip
  • 6 posts
  • Car:octavia estate

Posted 26 November 2010 - 05:39

Hi i have a skoda octavia 04 1.9 diesel the turbo sticks causing the engine to go into limp mode. has anyone tried cleaning their turbo with innoec turbo cleaner, if so is it easy, or does anyone know where in cheshire i could get my turbo cleaned. many thanks dave

#2 ap0gee1978

ap0gee1978

    Now with added vintage.

  • Honorary
  • PipPipPipPipPipPipPip
  • 10,481 posts

Posted 26 November 2010 - 08:03

http://briskoda.net/...ost__p__1393357

http://briskoda.net/...ost__p__1660711

http://briskoda.net/...ost__p__2133759

http://briskoda.net/...ost__p__2078477

#3 mbames

mbames

    Briskodian

  • Members
  • PipPipPipPipPipPip
  • 6,980 posts

Posted 26 November 2010 - 10:39

to be honest if the cleaner works on the air side of the, and not the exhaust side, then the use of it is going to be pretty pointless. Whip it off and give it a good clean.

I'll try and upload some pics of mine pre and post clean.

#4 rwbaldwin

rwbaldwin

    Briskodian

  • FREEDOM
  • PipPipPipPipPipPip
  • 6,258 posts
  • Car:Octavia TDi 110

Posted 26 November 2010 - 12:25

It doesn't work. For it be any use it would need to be sprayed directly onto the vanes, actuator ring and butterfly levers. This just isn't possible to do in-situ.

A mate bought a can. He removed the exhaust, sprayed the whole can in and he left it to do its stuff. I suggested that he pull off the vacuum hose and move the lever about a hundred times which he did. It seemed to solve the problem for a couple of months, but then it came back. His turbo wasn't completely solid to start with. When the problem returned, I took out the turbo and it was clear that some of the butterfly levers and part of the ring hadn't been touched. Where the cleaner had been, the hard carbon deposits remained.

Remove the turbo and clean it properly.

#5 davemcd63

davemcd63

    Briskodian

  • Members
  • Pip
  • 6 posts
  • Car:octavia estate

Posted 26 November 2010 - 22:05

It doesn't work. For it be any use it would need to be sprayed directly onto the vanes, actuator ring and butterfly levers. This just isn't possible to do in-situ.

A mate bought a can. He removed the exhaust, sprayed the whole can in and he left it to do its stuff. I suggested that he pull off the vacuum hose and move the lever about a hundred times which he did. It seemed to solve the problem for a couple of months, but then it came back. His turbo wasn't completely solid to start with. When the problem returned, I took out the turbo and it was clear that some of the butterfly levers and part of the ring hadn't been touched. Where the cleaner had been, the hard carbon deposits remained.

Remove the turbo and clean it properly.



#6 davemcd63

davemcd63

    Briskodian

  • Members
  • Pip
  • 6 posts
  • Car:octavia estate

Posted 26 November 2010 - 22:06

Thanks for your advice everybody . much appreciated

#7 mbames

mbames

    Briskodian

  • Members
  • PipPipPipPipPipPip
  • 6,980 posts

Posted 27 November 2010 - 11:36

Here is the main gallery of pictures: http://www.matthewam...112_turbo_clean

Some pictures of specific interest:

Dirty control:
Posted Image

Dirt around the control ring:
Posted Image

Dirty/oily vanes:
Posted Image

Clean vanes:
Posted Image

Clean control side:
Posted Image

All back together + elephant:
Posted Image

#8 alexandjen

alexandjen

    No Longer an Octi Owner

  • Members
  • PipPipPipPip
  • 911 posts
  • Location:Sittingbourne, Kent
  • Car:SOLD: 2002 Octavia Elegance Estate 1.9TDI 110 ASV Diamond Silver

Posted 27 November 2010 - 12:28

Just had a look at all your pics - that's some transformation :thumbup:

What did you use chemical wise for the cleaning process?

She must respond a lot better now?

#9 mbames

mbames

    Briskodian

  • Members
  • PipPipPipPipPipPip
  • 6,980 posts

Posted 27 November 2010 - 18:13

Just had a look at all your pics - that's some transformation :thumbup:

What did you use chemical wise for the cleaning process?

She must respond a lot better now?


Toothbrush, one of those green panscrub things and fairy washing up liquid can do more than just your dishes.... it loves turbos too :rofl: Oh and my mothers kitchen sink (when she wasn't watching!). Also cleaned up the inlet manifold and EGR/anti-shudder pipework again. Having now done the elephant mod, and EGR blank off, that pipework should remain clear. I am due a cambelt in few k's time, so I might take the intercooler off and wash that out too.

It is like a different car.... amazing. I am annoyed with myself that I took so long to sort it out. I can overtake and not worry about it going into limp mode midway through the manoeuvre.
