This is just a start of a project to have the engine bay marked up with dimensions, some of them i used for constraints so any others have been worked out by scaling.

let me know if this would be useful for me to carry on and its accuracy up to now (my cars away in the garage so i cant be bothered double checking lol)

Mike

Quite helpful for me mate anychance you could measure the dimensions for the air box area? Need to know how much room i have to work with for my custom intake : )

Absolutely no problem, i mean these are just quite rough as its a picture thats been scaled to fit in cad. Then i dimension anything i want to find out. Crude but gives an indication

Would be interesting to know the dimensions and depths of the area where the air box is fitted

Edit

Beaten to it

sorted Sy?
