Anacoth

Exemple : https://www.amazon.fr/LUOWAN-Electriques-Electrique-Connecteurs-Assortiment/dp/B093YQN69X/ref=asc_df_B093YQN69X?mcid=4bfdc8b8ed253cfd899bb917cbf61282&tag=googshopfr-21&linkCode=df0&hvadid=701535511807&hvpos=&hvnetw=g&hvrand=3370780012292695921&hvpone=&hvptwo=&hvqmt=&hvdev=m&hvdvcmdl=&hvlocint=&hvlocphy=9110207&hvtargid=pla-1310550801270&psc=1&gad_source=1 "cosse plate" in French

I bought and received a camera connected to the CAN bus, powered via the connector behind the car radio, with guideline No need to activate the camera via VCDs it does it alone, however I get a black screen, no image I don't know if I can do anything knowing that the game is checked via VCDs, in 5f, byte 19, bit 4 is activated I can't reverse the video wires because the new little blue connector is not openable like the original one In the description of what I ordered it is indicated that it only works on Octavia from 2015 (be careful in China the Octavia 3 5E is called the Octavia 3 A7 and arrived later), the mine is from 2013 with amundsen mib1 Thanks in advance if you have an idea https://a.aliexpress.com/_EGAgVbL

And me ?

Following this discussion I modified the wiring of the 12v cigarette lighter sockets on my Octavia so that it was powered by the rear windshield wiper. For more, I invite you to consult my thread https://www.briskoda.net/forums/topic/519871-switch-off-cigarette-ligther-12v-when-car-closed/?do=findComment&comment=5819431

I solved my problem by connecting the cigarette lighter sockets (fuse 40), instead of the fuse, to the power supply for the rear windshield wiper (fuse 47). To do this I used a “tap” fuse holder and a flat tip

Yes but this is tiny and will take weeks, not like an icebox where the verdict will come within a day

I have no idea, I just hope the Germans aren't that stupid and have thought about this. For the "3rd party cut out system" it's unclear to me, I use a translator and once converted into my language it means nothing

OK i don't have android auto No possibility of cutting off the 12v so... I still hope that the car will go into energy saving mode which will deactivate the accessories so that the battery level becomes critical to Start engine

This is exactly what I described at the beginning, there are no wires in front of the low position for fuse 40, unlike the Golf 7 for example. What do you call automatic dongle?

I'm not English speaker, with a translator I'm not sure understand well (translation of technical terms) can you send a link of the material are talking about? no way to make the cut without adding something else, with a computer and VCDS? Thank you

Me too ! Thanks you very much

Hello on my octavia 3 I am trying to deactivate the 12v after ignition because currently my 12v cigarette lighter sockets are permanently powered even when the car has been closed for several hours, it is annoying because I often have an electric cooler in the trunk and sometimes I forget to unplug it. I saw on the Golf 7 forums that it was necessary to move fuse number 40 to the bottom but on the Octavia I don't have a connection pin on the fuse box and therefore it doesn't work. Would you know how to do it? I have access to Vcds / vagcom. thank you so much

I'm interested too, impossible to find a download link

Haha well donne ! I didn't need a translator

Hi I have an Octavia 3 from 2013 and I seem to have an Amundsen MIB1 in version 0421 and I would like to install a reversing camera. I have read all the pages on this subject and the information is a bit mixed in my mind, plus all the video or photo links are dead so not easy to understand. If I understood correctly I need to enlarge the hole in the trunk handle if I want a similar mounting to the original, or a camera to mount on the license plate lighting or between the handle and the lighting by drilling. I have to be careful to take an ntsc camera and the often optimistic viewing angle on aliexpress. Should I pass the cable to the left or right? On the left there is the cable guide for the trunk, on the right you arrive directly at the glove box but you have to buy a cable guide for the trunk (ref: 1Z9 971 829)? Should I power the camera and the signal on a reversing light, the windshield wiper or a +12v from the fuse box? I saw on aliexpress that a 12v filter is provided in certain kits (example: https://a.aliexpress.com/_EwP7got) or via VCDS it is necessary to modify to have a pure 12v on the reversing light when the engine is started I would like to be able to watch via the camera while driving forward (control the trailer for example), is this possible by pressing the button to activate the parking sensors? If so I imagine that you have to power the camera other than through the reversing light With my firmware 0421 (which is lower than 0435), when I go to reverse I will have the camera screen with above on the left the symbol of the car with parking sensors on a black background (non-transparent) which gives me will hide the view and I will have to manually hide it every time? If you have a valid photo because I have a hard time imagining what it looks like (the photos in post 33 of Trust2K no longer work) Is an update really risky? 0490 is the last one? No matter how much I search, I really can't find it. I have the steering wheel angle sensor since when I reverse I have the steering angle on the Park assist screen, so I can mount a turning line camera "highline" from AliExpress or that complicates it a little more ? Thank you very much for the help provided I'm not english, I mix school memory and translate if necessary Ps: in your opinion, is all the hassle of studying, choosing, installing the reversing camera worth it or is it more of a comfort option, a bit of a gadget when you already have parking sensors? [URL=https://www.casimages.com/i/23122411010026107118325132.png.html][IMG]https://nsm09.casimages.com/img/2023/12/24//mini_23122411010026107118325132.png[/IMG] [/url] [URL=https://www.casimages.com/i/23122411010026107118325133.png.html][IMG]https://nsm09.casimages.com/img/2023/12/24//mini_23122411010026107118325133.png[/IMG] [/url]
