Cable identification - Head Unit replacement

Featured Replies

Hi,

First post here, but i'm long time lurker, and i got a lot of good information on this forum, so first of all, thank you all!



I replace my Bolero by a third party head unit with wireless android auto.



Everything seems to work nicely, but there is a cable i could not connect (didn't find any thing to plug it in)



The cable is coming from the dashboard side, and it has 12 pin if i remember correctly.



This cable follow a cable with a blue plastic head (antenna i think?)



Can anyone tell me what is the purpose of this cable?



Thank you!

  • Author

I figured it out, it's the cable connecting the "compute" unit with the screen unit.



Now i need to remove this compute unit, because it take to much place.
