Part numbers please

Featured Replies

Hello, i'd like to get the part numbers for some parts please.

they are

Metal undertray and any things that might need to be installed to fit it

door motor and regulator numbers for all doors

head light motor (both left and right)

roof lining

the car's info (from VW Group VIN Decoder)

Škoda Octavia Combi Ambiente 1.6 MPI 74kw

model year 2004, production number 891168

thanks

For the complete metal undertray you need:

1JO 018 930 C Engine and gearbox guard (x1)

1JO 018 885 A Retainer (x2)

N908 106 01 riveted cap nuts (x7)

N100 704 03 Bolts (x7)

1JO 018 977A Buffers (x3)

1JO 018 967A Retainers (x3)

N908 704 01 Bolts (x2)

Headlight Motor 1J0 941 295A (Seem to be the same for both sides)

Regulator Motor

OSF: 1U6 959 802 B

OSR: 1U0 959 812 B

NSF: 1U6 959 801 B

NSR: 1U0 959 811 B

What colour is your roof lining and do you have a sunroof?

  • Author

no sunroof, the lining is grey-ish
