9472881/9472882 - Motor for Fresh Air / Recirculated Air Flap - B108B - Actuator Stuck

[johnjohn]

During an AutoScan, I found the following fault:

Address 08: Auto HVAC (J255) Labels: 5K0-907-044.clb

Part No SW: 3T0 907 044 AK HW: 3T0 907 044 AK

Component: Climatronic H14 0302

Revision: 00004001

Coding: 0000000000

Shop #: WSC 31414 790 00001

ASAM Dataset: EV_Climatronic A01001

ROD: EV_Climatronic_SK35.rod

VCID: 7BDB258F4125

1 Fault Found:

9472881 - Motor for Fresh Air / Recirculated Air Flap

B108B 71 [009] - Actuator stuck

Freeze Frame:

Fault Status: 00000001

Fault Priority: 2

Fault Frequency: 81

Reset counter: 243

Mileage: 16176 km

Date: 2017.14.03

Time: 13:29:39

I tried to erase the fault code but it came back.

I then performed Basic Settings selecting only "Adjust flap end stops"; it "Finished correctly".

Since then, two faults appear:

Address 08: Auto HVAC Labels: 5K0-907-044.CLB

Control Module Part Number: 3T0 907 044 AK HW: 3T0 907 044 AK

Component and/or Version: Climatronic H14 0302

Software Coding: 0000000000

Work Shop Code: WSC 31414 790 00001

ASAM Dataset: EV_Climatronic A01001 (SK35)

VCID: 7BDB258F4125

2 Faults Found:

9472881 - Motor for Fresh Air / Recirculated Air Flap

B108B 71 [009] - Actuator stuck

Freeze Frame:

Fault Status: 00000001

Fault Priority: 2

Fault Frequency: 2

Reset counter: 243

Mileage: 16415 km

Date: 2019.14.02

Time: 15:06:49

9472882 - Motor for Fresh Air / Recirculated Air Flap

B108B 72 [009] - Actuator stuck open

Freeze Frame:

Fault Status: 00000001

Fault Priority: 2

Fault Frequency: 1

Reset counter: 243

Mileage: 16415 km

Date: 2019.14.02

Time: 15:06:25

They both re-appear every time I clear them.

No modifications have been made on the car and the Climatronic seems to work fine.

I tried searching Ross-Teck Wiki for 9472881/9472882/B108B but I didn't find anything.

Any suggestions on how to get rid of these two faults?

Thanks in advance.

Complete AutoScan (when I initially discovered the fault):

VCDS Version: Beta 11.2.0

Data version: 20110305

Sunday,13,March,2011,14:56:52:48106

Chassis Type: 1K0

Scan: 01 03 08 09 15 16 17 19 25 42 44 46 52 56 62 72

VIN: TMBBJ21Z1AC(six digits removed)

01-Engine -- Status: OK 0000

03-ABS Brakes -- Status: OK 0000

04-Steering Angle -- Status: OK 0000

08-Auto HVAC -- Status: Malfunction 0010

09-Cent. Elect. -- Status: OK 0000

15-Airbags -- Status: OK 0000

16-Steering wheel -- Status: OK 0000

17-Instruments -- Status: OK 0000

19-CAN Gateway -- Status: OK 0000

25-Immobilizer -- Status: OK 0000

42-Door Elect, Driver -- Status: OK 0000

44-Steering Assist -- Status: OK 0000

46-Central Conv. -- Status: OK 0000

52-Door Elect, Pass. -- Status: OK 0000

56-Radio -- Status: OK 0000

62-Door, Rear Left -- Status: OK 0000

72-Door, Rear Right -- Status: OK 0000

-------------------------------------------------------------------------------

Address 01: Engine (CAX) Labels: 03C-906-016-CAX.clb

Part No SW: 03C 906 016 D HW: 03C 906 016 C

Component: MED17.5.5 3981

Revision: LCH02--- Serial number:

Coding: 0000072

Shop #: WSC 31414 790 00001

VCID: 206132E38803

No fault code found.

Readiness: 0000 0000

-------------------------------------------------------------------------------

Address 03: ABS Brakes Labels: 1K0-907-379-MK70M.lbl

Part No SW: 1K0 907 379 AQ HW: 1K0 907 379 AQ

Component: MABS MK70M 0105

Revision: 00H32001

Coding: 0016641

Shop #: WSC 31414 790 00001

VCID: 8127D767A3C9

No fault code found.

-------------------------------------------------------------------------------

Address 08: Auto HVAC (J255) Labels: 5K0-907-044.clb

Part No SW: 3T0 907 044 AK HW: 3T0 907 044 AK

Component: Climatronic H14 0302

Revision: 00004001

Coding: 0000000000

Shop #: WSC 31414 790 00001

ASAM Dataset: EV_Climatronic A01001

ROD: EV_Climatronic_SK35.rod

VCID: 7BDB258F4125

1 Fault Found:

9472881 - Motor for Fresh Air / Recirculated Air Flap

B108B 71 [009] - Actuator stuck

Freeze Frame:

Fault Status: 00000001

Fault Priority: 2

Fault Frequency: 81

Reset counter: 243

Mileage: 16176 km

Date: 2017.14.03

Time: 13:29:39

-------------------------------------------------------------------------------

Address 09: Cent. Elect. (J519) Labels: 1K0-937-08x-09.clb

Part No SW: 1K0 937 087 D HW: 1K0 937 087 D

Component: BCM PQ35 H 103 0537

Revision: 00103 AB

Coding: 46180AB8B80508C000080001150081EC034100AE400089605C0440000000

Shop #: WSC 31414 790 00001

VCID: 3245C8ABD6EF

Subsystem 1 - Part No: 1Z1 955 119 C

Component: Wischer 11050 22 0601

Coding: 00D7B7

No fault code found.

-------------------------------------------------------------------------------

Address 15: Airbags Labels: 1K0-909-605.lbl

Part No SW: 1K0 909 605 T HW: 1K0 909 605 T

Component: Q2 AIRBAG VW8 020 2300

Revision: 05020000 Serial number: 0038PD2DHEAJ

Coding: 0020786

Shop #: WSC 31414 790 00001

VCID: 3D5FEB971FB1

No fault code found.

-------------------------------------------------------------------------------

Address 16: Steering wheel Labels: 1K0-953-549-MY9.lbl

Part No SW: 1K0 953 549 CE HW: 1K0 953 549 CE

Component: J0527 055 0111

Coding: 0000501

Shop #: WSC 31414 790 00001

VCID: 77D339BF7D0D

Subsystem 1 - Part No: 3T0 959 537

Component: E221__MFL-URO H07 0011

Coding: 00000128

Shop #: WSC 00000

No fault code found.

-------------------------------------------------------------------------------

Address 17: Instruments (J285) Labels: 5K0-920-xxx-17.clb

Part No SW: 1Z0 920 843 B HW: 1Z0 920 843 B

Component: KOMBI H21 0109

Serial number: 00000000000000

Coding: 110B00

Shop #: WSC 31414 790 00001

ASAM Dataset: EV_Kombi_UDS_VDD_RM09 A04040

ROD: EV_Kombi_UDS_VDD_RM09_SK35.rod

VCID: 3753F9BF3D8D

No fault code found.

-------------------------------------------------------------------------------

Address 19: CAN Gateway Labels: 1K0-907-530.lbl

Part No SW: 1K0 907 530 AA HW: 1K0 907 951

Component: J533 Gateway H16 0222

Revision: H16 Serial number: 4020K095080620

Coding: E9807F06000202001302

Shop #: WSC 31414 790 00001

VCID: 66ED64FB2AA7

No fault code found.

-------------------------------------------------------------------------------

Address 25: Immobilizer (J334) Labels: 5K0-920-xxx-25.clb

Part No SW: 1Z0 920 843 B HW: 1Z0 920 843 B

Component: IMMO H21 0109

Serial number: 00000000000000

ASAM Dataset: EV_Immo_UDS_VDD_RM09 A03004

ROD: EV_Immo_UDS_VDD_RM09_SK35.rod

VCID: 3753F9BF3D8D

No fault code found.

-------------------------------------------------------------------------------

Address 42: Door Elect, Driver Labels: 1K0-959-701-MAX3.lbl

Part No SW: 1T0 959 701 AA HW: 1T0 959 701 AA

Component: Tuer-SG 009 2107

Coding: 0004342

Shop #: WSC 31414 790 00001

VCID: 76CD34BB7A07

No fault code found.

-------------------------------------------------------------------------------

Address 44: Steering Assist Labels: 1Kx-909-14x.lbl

Part No: 1K0 909 144 H

Component: EPS_ZFLS Kl. 68 2901

Revision: 00H15000

Shop #: WSC 31414 790 00001

VCID: 2F43C1DFC5DD

No fault code found.

-------------------------------------------------------------------------------

Address 52: Door Elect, Pass. Labels: 1K0-959-702-MAX3.lbl

Part No SW: 1T0 959 702 S HW: 1T0 959 702 S

Component: Tuer-SG 009 2107

Coding: 0004342

Shop #: WSC 31414 790 00001

VCID: 48B18A434073

No fault code found.

-------------------------------------------------------------------------------

Address 56: Radio (J503) Labels: 5M0-035-1xx-56.clb

Part No SW: 1Z0 035 161 F HW: 1Z0 035 161 F

Component: SWING 008 0062

Revision: 0H001001 Serial number: SKZ1Z2I8242386

Coding: 050004000001

Shop #: WSC 31414 790 00001

VCID: 3147C7A7D3E9

No fault code found.

-------------------------------------------------------------------------------

Address 62: Door, Rear Left Labels: 1K0-959-703-GEN3.lbl

Part No SW: 5K0 959 703 A HW: 5K0 959 703 A

Component: Tuer-SG 007 2101

Coding: 0000144

Shop #: WSC 31414 790 1012545

VCID: 3245C8ABD6EF

No fault code found.

-------------------------------------------------------------------------------

Address 72: Door, Rear Right Labels: 1K0-959-704-GEN3.lbl

Part No SW: 5K0 959 704 A HW: 5K0 959 704 A

Component: Tuer-SG 007 2101

Coding: 0000144

Shop #: WSC 31414 790 1012545

VCID: 334BCDAF29F5

No fault code found.

End ---------------------------------------------------------------------

[Dana@Ross-Tech]

Address 08: Auto HVAC (J255) Labels: 5K0-907-044.clb

Part No SW: 3T0 907 044 AK HW: 3T0 907 044 AK

Component: Climatronic H14 0302

Revision: 00004001

Coding: 0000000000

Shop #: WSC 31414 790 00001

ASAM Dataset: EV_Climatronic A01001

ROD: EV_Climatronic_SK35.rod

VCID: 7BDB258F4125

1 Fault Found:

9472881 - Motor for Fresh Air / Recirculated Air Flap

B108B 71 [009] - Actuator stuck

That looks like the motor is actually stuck, or the flap door has an obstruction of some sort. Since this is the Recirc. Flap I'm guessing it's very near the Air Pollen filter. If that's like the VW equivalent, I think you can remove the pollen filter and gently push the flap door or look at the movement while running Basic Settings. I would not prevent it from moving during the test, but see if it sticks.

[johnjohn]

That looks like the motor is actually stuck, or the flap door has an obstruction of some sort. Since this is the Recirc. Flap I'm guessing it's very near the Air Pollen filter. If that's like the VW equivalent, I think you can remove the pollen filter and gently push the flap door or look at the movement while running Basic Settings. I would not prevent it from moving during the test, but see if it sticks.

Thanks Dana.

Can anyone confirm that, on Skoda Octavia 2 Facelift, by removing the air pollen filter I will actually be able to see the air recirculation flap?

[rum4mo]

But, you've been given some sound advice - why can't you not just go and use it, then report back, instead of asking questions about the answer given?

[z klasse]

There are two flaps.. One for outside air and there is one inside for the AC when you turn on the switch. The one for the AC to be accessed, you need to remove the glove compartment and its just behind that on the top. The one for the outside air can be seen after removing the cabin filter. The error that you have seems to be of the top one.

[RJVB]

On 12/10/2018 at 06:20, z klasse said:

There are two flaps.. One for outside air and there is one inside for the AC when you turn on the switch. The one for the AC to be accessed, you need to remove the glove compartment and its just behind that on the top. The one for the outside air can be seen after removing the cabin filter. The error that you have seems to be of the top one.



Re-reviving this old thread since I just found the same fault in my diagnostics.



The top one is the hard-to-access one, the one related to the AC?



Any chance that this is why I my airco isn't (or seems not to be) working?
