Fault code - Engine Malfunction

admirator

By admirator
in Skoda Superb Mk II (2008-2015)

 Share

Recommended Posts

admirator Rookie

admirator

Posted
Posted

Hi,

Recently i noticed a text on the MID that read "Engine Fault Workshop" it disappeared within a second.



I later conducted a VCDS scan and found this.



VIN: TMBBBG3T7AA3074477   Mileage: 57530km-35747miles

01-Engine -- Status: Malfunction 0010
03-ABS Brakes -- Status: OK 0000
04-Steering Angle -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: Malfunction 0010
10-Park/Steer Assist -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
25-Immobilizer -- Status: OK 0000
36-Seat Mem. Drvr -- Status: OK 0000
42-Door Elect, Driver -- Status: OK 0000
44-Steering Assist -- Status: OK 0000
46-Central Conv. -- Status: OK 0000
4C-Tire Pressure II -- Status: OK 0000
52-Door Elect, Pass. -- Status: OK 0000
55-Headlight Range -- Status: OK 0000
56-Radio -- Status: OK 0000
62-Door, Rear Left -- Status: OK 0000
72-Door, Rear Right -- Status: OK 0000
77-Telephone -- Status: OK 0000

-------------------------------------------------------------------------------
Address 01: Engine (CDA)       Labels: 06J-907-115-CDA.clb
   Part No SW: 3T0 907 115 G    HW: 1Z0 907 115 F
   Component: 1.8l R4/4V TFSI     0010
   Revision: AAH17---    Serial number:
   Coding: 0203000C18070160
   Shop #: WSC 33361 790 00081
   VCID: 3566FA965CDA36E90A-8060

1 Fault Found:
000833 - Camshaft Position Sensor (G40)
               P0341 - 000 - Implausible Signal - Intermittent
             Freeze Frame:
                    Fault Status: 00100000
                    Fault Priority: 0
                    Fault Frequency: 1
                    Reset counter: 255
                    Mileage: 57535 km
                    Time Indication: 0
                    Date: 2012.01.25
                    Time: 16:58:40

             Freeze Frame:
                    RPM: 1548 /min
                    Load: 22.3 %
                    Speed: 24.0 km/h
                    Temperature: 93.0°C
                    Temperature: 48.0°C
                    Absolute Pres.: 900.0 mbar
                    Voltage: 13.589 V

Readiness: 0010 0000

-------------------------------------------------------------------------------
Address 03: ABS Brakes (J104)       Labels: 1K0-907-379-60EC1F.clb
   Part No SW: 1K0 907 379 AJ    HW: 1K0 907 379 AJ
   Component: ESP MK60EC1   H30 0107
   Revision: 00H30001
   Coding: 863D6016092200FB611306EB90200081350C00
   Shop #: WSC 33361 790 00081
   VCID: 7AFC29AAF5441991A7-802E

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC (J255)       Labels: 5K0-907-044.clb
   Part No SW: 3T0 907 044 AR    HW: 3T0 907 044 AR
   Component: Climatronic   H15 0401
   Revision: 00005001
   Coding: 0000001002
   Shop #: WSC 33361 790 00999
   ASAM Dataset: EV_Climatronic A01006
   ROD: EV_ClimaAutoBasis_SK35.rod
   VCID: 020C514A95945151FF-8056

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519)       Labels: 1K0-937-08x-09.clb
   Part No SW: 1K0 937 087 P    HW: 1K0 937 087 P
   Component: BCM PQ35  H+  104 0615
   Revision: 00104 AE
   Coding: 48990A27E85BF1C0C0080081110089EC477000AE73208920640000000040
   Shop #: WSC 33361 790 00999
   VCID: 3E74E5BAA9ECF5B1DB-806A

   Subsystem 1 - Part No: 3T2 955 119   Labels: 1KX-955-119.CLB
   Component: Wischer 13051  22  0602
   Coding: 00D7B7

   Subsystem 2 - Part No: 1K0 955 559 AH  Labels: 1K0-955-559-AG.CLB
   Component: RLS 110510 05  54  0403
   Coding: 0730ED

   Subsystem 3 - Part No: 1K8 951 171
   Component: DWA-Sensor 00  001 0104

   Subsystem 4 - Part No: 1K0 951 605 C
   Component: LIN BACKUP HO  H05 1501

1 Fault Found:
01504 - Bulb for License-Plate Light (X)
            014 - Defective - Intermittent
             Freeze Frame:
                    Fault Status: 00101110
                    Fault Priority: 2
                    Fault Frequency: 3
                    Reset counter: 218
                    Mileage: 57513 km
                    Time Indication: 0
                    Date: 2012.01.24
                    Time: 21:52:31

             Freeze Frame:
                        Term 15 On
                    Voltage: 12.20 V
                        ON
                        ON
                        Term 50 Off
                        OFF
                        OFF


-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446)       Labels: 1Z0-919-475-V1.clb
   Part No SW: 1Z0 919 475 C    HW: 1Z0 919 475 A
   Component: PARKHILFE 8K  H06 0006
   Revision: --------    Serial number: 66541011207762
   Coding: 100004
   Shop #: WSC 33361 790 00081
   VCID: 418E9E46D8128A49A6-8014

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags        Labels: 5N0-959-655.lbl
   Part No SW: 3T0 959 655 B    HW: 3T0 959 655 B
   Component: J234__LD7 VW10 HI   1916
   Revision: 19014000    Serial number: 003GRP8RP9T/
   Coding: 0017463
   Shop #: WSC 33361 790 00081
   VCID: 40889B4213188341A9-8014

   Subsystem 1 - Serial number: 6332MTS605341200

   Subsystem 2 - Serial number: 6342MTS622691130

   Subsystem 3 - Serial number: 6351HTS6TFKLA6KJ

   Subsystem 4 - Serial number: 6361HTS6IUMLA6KR

   Subsystem 5 - Serial number: 63727TS6HVNV79KJ

   Subsystem 6 - Serial number: 00000000000000000

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527)       Labels: 5K0-953-569.clb
   Part No SW: 1K5 953 521 AK    HW: 5K0 953 569 B
   Component: LENKS.MODUL   009 0135
   Revision: FF010036    Serial number: 20100529100367
   Coding: 008A140000
   Shop #: WSC 33361 790 00999
   ASAM Dataset: EV_SMLSNGVOLWS A01004
   ROD: EV_SMLSNGVOLWSXS.rod
   VCID: 76E43D9AC95C7DF1C3-8022

   Multifunction steering wheel control module:
   Subsystem 1 - Part No SW: 3T0 959 537     HW: 3T0 959 537   Labels: 3C8-959-537.CLB
   Component: E221__MFL-URO  H07 0012
   Coding: 820000

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments (J285)       Labels: 5K0-920-xxx-17.clb
   Part No SW: 3T2 920 841 G    HW: 3T2 920 841 G
   Component: KOMBI         H04 0406
   Serial number: 00000000000000
   Coding: 110F01
   Shop #: WSC 33361 790 00999
   ASAM Dataset: EV_Kombi_UDS_VDD_RM09 A04089
   ROD: EV_Kombi_UDS_VDD_RM09_SK46.rod
   VCID: 3878F3A283C8CB8111-806C

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway        Labels: 7N0-907-530-V1.clb
   Part No SW: 7N0 907 530     HW: 1K0 907 951
   Component: J533  Gateway   H27 0602
   Revision:   H27       Serial number: 130510F2000758
   Coding: E9B1FF0600060200003303
   Shop #: WSC 33361 790 00999
   VCID: 6DD612F6740ABE2932-8038

No fault code found.

-------------------------------------------------------------------------------
Address 25: Immobilizer (J334)       Labels: 5K0-920-xxx-25.clb
   Part No SW: 5K0 953 234     HW: 5K0 953 234
   Component: IMMO          H04 0406
   Serial number: 00000000000000
   Coding: 000000
   Shop #: WSC 00000 000 00000
   ASAM Dataset: EV_Immo_UDS_VDD_RM09 A03008
   ROD: EV_Immo_UDS_VDD_RM09_VW21.rod
   VCID: 6ADC19EA8DE4A91157-803E

No fault code found.

-------------------------------------------------------------------------------
Address 36: Seat Mem. Drvr        Labels: 3C0-959-760.lbl
   Part No SW: 3C8 959 760     HW: 3C8 959 760
   Component: J810                0801
   Revision: 00002000    Serial number: 00000000000000
   Coding: 0000003
   Shop #: WSC 00000 000 00000
   VCID: 72EC018A6D3461D1EF-8026

No fault code found.

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386)       Labels: 8X0-959-793.clb
   Part No SW: 8X0 959 793 C    HW: 8X0 959 793 C
   Component: TSG FA        H09 0409
   Revision: --------    Serial number: --------------
   Coding: 011D0220DE01001000
   Shop #: WSC 33361 790 00999
   VCID: 4D96B276144A5E2952-8018

No fault code found.

-------------------------------------------------------------------------------
Address 44: Steering Assist        Labels: 1Kx-909-14x-44.clb
   Part No: 1K0 909 144 J
   Component: EPS_ZFLS Kl. 195    3001
   Revision: 00H17000
   Shop #: WSC 33361 790 00999
   VCID: 316ECE86A8B21AC956-8064

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387)       Labels: 8X0-959-792.clb
   Part No SW: 8X0 959 792 C    HW: 8X0 959 792 C
   Component: TSG BF        H09 0409
   Revision: --------    Serial number: --------------
   Coding: 011D0220DE01001000
   Shop #: WSC 33361 790 00081
   VCID: 4C90BF72EF50572145-8018

No fault code found.

-------------------------------------------------------------------------------
Address 55: Headlight Range        Labels: 5M0-907-357-V2.lbl
   Part No SW: 5M0 907 357 C    HW: 5M0 907 357 C
   Component: AFS-Steuergeraet    0142
   Revision: 00H04000    Serial number:
   Coding: 1377095
   Shop #: WSC 06821 002 1048576
   VCID: 3460C79257A02FE13D-8060

   Subsystem 1 - Part No: 7L6 941 329 B  Labels: 3D0-941-329.CLB
   Component: AFS-Lst.-Modul l    0004
   Coding: 00000021

   Subsystem 2 - Part No: 7L6 941 329 B  Labels: 3D0-941-329.CLB
   Component: AFS-Lst.-Modul r    0004
   Coding: 00000021

No fault code found.

-------------------------------------------------------------------------------
Address 56: Radio (J503)       Labels: 5M0-035-1xx-56.clb
   Part No SW: 3T0 035 156 C    HW: 3T0 035 156 C
   Component: BOLERO        013 0029
   Revision: -----27S    Serial number: SKZ4Z3K1101617
   Coding: 0D0004000004
   Shop #: WSC 33361 790 00081
   VCID: 2E54D5FA798C05314B-807A

No fault code found.

-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388)       Labels: None
   Part No SW: 8X0 959 795 B    HW: 8X0 959 795 B
   Component: TSG HL        H06 0409
   Revision: --------    Serial number: --------------
   Coding: 010C00200001001000
   Shop #: WSC 33361 790 00999
   VCID: 4E94B57A194C65312B-801A

No fault code found.

-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389)       Labels: None
   Part No SW: 8X0 959 795 B    HW: 8X0 959 795 B
   Component: TSG HR        H06 0409
   Revision: --------    Serial number: --------------
   Coding: 010C00200001001000
   Shop #: WSC 33361 790 00081
   VCID: 4E94B57A194C65312B-801A

No fault code found.

-------------------------------------------------------------------------------
Address 77: Telephone (J412)       Labels: 7P6-035-730.clb
   Part No SW: 7P6 035 730 C    HW: 7P6 035 730 C
   Component: TELEFON       H05 0440
   Revision: 1B001001    Serial number: 00007668097028
   Coding: 0200000000010110
   Shop #: WSC 33361 790 00999
   ASAM Dataset: UHVNA A01007
   ROD: UHVNA.rod
   VCID: 326CC18A65B421D12F-8066

No fault code found.

End-------------------------(Elapsed Time: 03:22)--------------------------



Request any Help on this. Thank you




Link to comment
Share on other sites
Gdcobra Rising Star

Gdcobra

Posted
Posted

I had the same message a few times not long after I bought my car back in April, probably about 200mile intervals.  I've been using 'quality' fuel and mainly doing long trips (that's how my mileage works out) and the issue appears to have gone away.  I'm putting it down to either something in the emission (DPF or EGR) being close to giving trouble which has improved with my driving style or possibly the battery was flattish which I know can give spurious errors.

I've not had a scan.
