  1. Its under the carpet probably corroded connections from water ingress
  2. Probably dirt on the switch contacts try electonic cleaner spray, are the hazards working? Have you ruled out fuses and relays?
  3. Hi high beam on these are halogen, low beam xenon, when mine stopped working it was the ballast attached to the under side of the lamp, start with the easy stuff to check fuses, swapping bulbs to rule these out and only work on it disconnected from power there is very high voltage. HELLA 5DV 008 290-004 Ballast, gas discharge lamp
  4. As above Passat B5/B5.5 there may be some differences indicator possibly
  5. These cars all leak water into the cabin through multiple failure points (pollen filter housing seal, doors plates, sunroof drains blocked, ecu housing seal, bonnet release cable seal to name a few) and they will lead to electrical nightmares of wiring corrosion if left unattended, do yourself a favour and have a read of that thread it could save you a lot especially if you recently got the car and dont know its history.
  6. Door locks are a common fault check ebay for replacements, get the battery tested under load to see if it needs replacing. Have you checked the car for water ingress?
  7. S0054040020-Electrical_System.pdfCentral control unit for convenience system -J393- Check Page 129 of this possibly corrsion from water ingress, have you scanned it for fault codes? The control unit is located in front of the driver seat under the floor covering
  8. Have a look at the B5/B5.5 Passat options they may fit.
  9. Are you sure the culprit is not the alternator clutch pulley?
  10. You need a new shifter handle right hand drive 3U2713139A ( the letter will denote the trim on it just go for the cheapest/available one)
  11. Use the search function with keywords 2.0PD 140, Oil pump drive etc you will find plenty there to keep you reading for the afternoon, filter for Superb Mk1 only so it limits the results
  12. Check the fuse could be that simple, but with these cars more likely wiring corrsion due to water ingress. Go onto Erwin and pay for an hour about €7.00 you should be able to download all the applicable info for the car.
  13. Look at the Passat B5.5 for some ideas that might work, stock fogs are in the headlight.
  14. Welcome to the forum, tumbleweeds blowing through here of late, have you addressed the oil pump drive issue with that engine?
×
×
