Guys, just in case its of any use to anyone that hasn't seen this in my project thread, I thought Id drop a copy in here also.... So, now an interesting development and the first negative of my Yeti ownership experience in the three and a half years I've had her. Ive often read that people have had issues with their panoramic sunroofs leaking into the foot wells of the car. However, ive never had an issue with water ingress and Ive even tried to make it leak in the past (being in warranty then!) with the use of a hose! The car has also been parked up in absolutely torrential storms in the last coupe of years (one was so bad that it almost trapped us in Altea, Spain by causing multiple landslides across the mountain roads below where we were staying!) But whatever conditions we've hit, the cabin has always remained 100% watertight. Therefore, you could probably guess how surprised I was to go to the car recently and see a few drips down the inside of the passenger foot well below the A-pillar. Admittedly, the rain over night was probably the longest and hardest we'd seen in years in the UK but I was surprised none the less! I removed a couple of internal panels to see if I could work out exactly where it was coming in. First I removed the dashboard passenger side end panel - I found a series of drips running down from above so that meant I had to remove the passenger side A pillar trim, higher up. This now gave me a clear look at the passenger side sunroof drain (in red) and the surrounding area. The drips were coming from higher up but I wanted to spend some time trying various methods of clearing any blockage before removing any more internal panels.... I tried different methods of clearing any blockage but I was concerned I could possibly cause more issue if I caught the rubber drainage duct internally with something too hard or from just being too aggressive. It was clear that there was certainly dirt and gunk built up inside the channels BUT when I poured water into the sunroof surround to test, most of it was appearing fairly quickly at the external drainage hole (the hole by the door hinge). Even though most was coming straight through and into the outside world.... there was still some dripping freely down the A pillar, internally into the cabin. So I carried on looking further up towards the roof... What I saw (and really didn't like) was the use of black cable ties directly onto the flexible rubber drainage pipe. The one at the top of the A-pillar appeared to have been done too tightly from the factory. Ive pulled the drainage channel down very slightly in the above photo so you can see the mark it had made. It was squeezing the rubber drain tight and restricting its flow by probably 30%. So, was this the problem? Well it certainly wasn't helping but the actual problem could be found still further up towards the sunroof surround... Having removed the rubber door sill slightly as well as the passenger interior grab handle and sunvisors from the roofs interior, I could just see up into the void between the interior roof skin and the sunroof surround. It looked as though the white connector on the end of the red drain channel was the part actually leaking. To me, it felt as though it had too much movement on the end of the black sunroof drain channel connector. So at this point I decided Id done enough investigating and hatched a proper plan to resolve not only this specific issue but to also ensure I wouldn't have the issue in the future... from either this or one of the other three sunroof drainage outlets. Over the course of the next three evenings I stripped the interior roof skin out so I had full and unhindered access to all four of the drainage outlets. Once done, how much effort did it take to see if my gut feeling was correct? Very little is the answer, the drainage pipe came away from the black connector far too easily for my liking. My plan: Remove each of the drainage outlets from the four corners of the sunroof frame surround. Clear out the drains properly by use of compressed air and cleaning agents that were kind to the rubber. Reattach the drain connectors with a specific waterproof sealer and adhesive. Cable tie the connectors to ensure a 100% watertight refit. Fully test for water tightness before refitting the internal trim panels. Just clearing out the drainage channels made a massive difference in how quickly water emptied from the sunroof surround to the ground via the four drainage point (front two by the door hinges, rear two out the back by the top of the tailgate). After my second evening, I ended up with this... Four connectors, all with waterproof sealant internally (very carefully done to ensure that none made its way to anywhere near the actual inside of the red drain pipe) as well as externally at the top of the white connector to the black sunroof frame surround and lower down on the underside of the white connector where it met with the red drainage pipe. Then I put a cable tie in place to ensure it was clamped tight. I wasn't taking any chances and wanted to do a proper job to save me any further issues in the future. Result: Problem cured and unlikely to happen again due to it being a better solution than the factory did imo and everything back together perfectly with no evidence of water ingress issues - mainly due to catching it quickly and resolving it within a couple of days. I can only assume that the heat and cold must loosen the connection between the hard plastic sunroof surround and the slightly softer plastic white connector over time. Trust it to finally 'let go' six months out of warranty but I'm happy with the fix.

Couldn't find procedure for start/stop engine switch replacement on Yeti, however this might be useful to others. Problem was start/stop switch was intermittent, spraying with contact cleaner worked but not for long. The steering cowl is in two halves, drop steering wheel to lowest position and prize off top one by hand or aided with blade between halves. Lift up out of the way which is restricted by fabric cover. Remove torx t25 screw underneath lower cowl and then remove two more screws that are exposed fully when steering wheel is rotated through 90 degrees left and right. With screws removed lower cowl can be dropped down and access to the switch to be replaced is now easily possible. Undo plug with locking tag and push switch out. Reverse procedure to reassemble. Good luck !!
