Cairus

almost finished

Firmware Train Jump need To Patch the Unit

Write PM with vin

You can send me the unit and I'll take a look at it.

What country does the vehicle come from? I simply cannot imagine that a Sportline model wouldn't have any of these features.

Light config Kodiaq1_FL_Matrix_BCM_Light_Config.txt

It also doesn't have an original crossover.

I recently did the work for someone with a Superb hybrid 2020 sound system without a subwoofer to find out the pinout. Pinout by Connection Controller: Center speaker (R208) T38a/5 & T38a17 in green & red/green Front left woofer (R21) T9a/5 & T9a/4 in white/blue & red/blue Front left midrange speaker (R103) T38a/19 & T38a/7 in red/green & white/green Front left tweeter (R20) T38a/21 & T38a/9 in red & white/red Front right woofer (R23) T9a/1 & T9a/2 in brown/blue & red/blue Front right midrange speaker (R104) T38a/20 & T38a/8 in red/green & brown/green Front right tweeter (R22) T38a/22 & T38a/10 in red & brown/red colors Rear Left Woofer (R15) T9a/7 & T9a/8 in black/blue & white/blue colors Rear Left Tweeter (R14) T38a/29 & T38a/37 in white/red & black/red colors Rear Right Woofer (R17) T9a/9 & T9a/6 in black/blue & brown/blue colors Rear Right Tweeter (R16) T38a/30 & T38a/38 in brown/red & black/red colors

The vehicles do not have a crossover from the OEM. Do you have three speakers per front door? If the vehicles do not have a factory-installed sound system, the frequency is split using a capacitor at the speaker. If the vehicle does have a sound system, the digital sound processor is located under the driver's seat (in the case of left-hand drive vehicles). This processor directly powers each speaker and is operated via coding and a data set at the sound processor.

Yes

Find a competent workshop... the ABS sensor is one of two components that measure wheel speed. The sensor is located at the wheel bearing where the ABS disc is integrated. In such cases, a diagnostic drive is performed to check the sensors and avoid replacing parts haphazardly.

What say the Error Log File?

On the J126 connector, the 4-pin connector is labeled T4ad/4 ---> Pin 4 ---> color violet/blue The counterpart is the J65, the 20-pin connector labeled T20e/16 ---> Pin 16

@Binx1310 Sorry, I need to correct you. The fresh air blower, labeled V2 in the wiring diagrams, has no connection to the BCM at all. It's a LIN SUB device connected to the Climatronic system. You have the power supply directly from fuse SC14 (30 amps), which is terminal 30, as well as ground from a central ground point, both 4 mm². The LIN connection is a 0.35 mm² cross-section and, as mentioned, goes to the Climatronic. Of course, you also have a potential source of error with the blower itself, VW calls it J126, the control unit for the fresh air blower. Personally, I would simply replace the blower and control unit. Of course, the blower alone is also available.

Yellow Airbag Black smal seat belt Black big, Seat

The connector looks more like a sound system connector to me.

You buy by AliExpress?

And which Controller you buy?

Is Not OEM

Sorry was for the Other User

Sorry this is With heating for Superb 3V0419091AFBGW

This? 5E0419091BC

So, you want me to add to the list. I'd like to, but I have no idea what the part numbers are on the steering wheels I bought. I'll have to remove the airbag at the next opportunity.

?

Of course, heated versions exist. I've even installed two of them. One with DSG in my manual transmission, because it only cost me €50 new and in its original packaging. I made that compromise. Then there's the adapter I built myself, my own version, for the correct function of the steering wheel buttons. The complete conversion, including the airbag, cost €230. I did the coding myself, of course.
