  1. To reduce noise from ratling, on that Striker loop (U-bar) which looks like the Greek letter Π i have added a layer of tape (Cloth of Fabric as they say it, not common electrical tape). Not too much to create problems in closing,keeps the hood more steady.
  2. A repair-shop visit needed or a friend of yours may have a VCDS in his laptop or even an OBD11 which works with a smartphone. Even if you perform an ECU-reset by yourself if there is an error it will show-up again soon, it must be erased. The coolant sensor is ''OK'' if you measure his contacts, from outside may look good but maybe it isn't. Check the hose connection in the fuel pressure regulator and in the intake manifold. The throttle body must be calibrated and do some Kilometres in normal driving so the ECU ''will learn'' your driving style, a scan tool is absolutely necessary in that case. I have changed mine plus 2 ECU units and also i had a vacuum leak in the past.
  3. When you replace the throttle body did you use a scan tool (OBD scanner) for possible error codes? Have you checked the coolant sensor? It's wires-contacts? The vacuum hose is checked?
  4. You should change everything you could taken from a set like this, was an A' class opportunity since you started the project.
  5. The ''feeling'' now is better when you change gears? My gear stick sense was very sloppy plus i has a problem in 3rd gear,it was shaking a bit and i always afraid that it will be disengage by itself. 😄
  6. Some maybe by mistake give it 9.7:1 https://www.autoparts-24.com/engine/code/136m/15047/ (Note: While some technical databases occasionally round this figure up to 10.0:1 for late-model variations, the official standard for the Škoda 781.136M high-output block is 9.7:1) Although https://www.ultimatespecs.com/car-specs/Skoda/5623/Skoda-Felicia-13-MPI-68.html https://www.scribd.com/document/956290892/Skoda-1300-Manual Compression Ratio 10:1
  7. Translation in english (NOT mine) Main Specifications & Key Data Engine Type 135 (Production: 09.94 ➔ | Displacement: 1.3 l | Power: 42 or 43 kW | Torque: 94 Nm | Compression Ratio: 8.8 | Fuel System: Carburetor JIKOV 28-30 LEKR) Engine Type 135B (Production: 09.94–08.96 | Displacement: 1.3 l | Power: 40 kW | Torque: 94 Nm | Compression Ratio: 8.8 | Fuel System: Mono-Motronic) Engine Type 136B (Production: 09.94–08.96 | Displacement: 1.3 l | Power: 50 kW | Torque: 100 Nm | Compression Ratio: 9.7 | Fuel System: Mono-Motronic) Engine Type 135M (Production: 08.96 ➔ | Displacement: 1.3 l | Power: 40 kW | Torque: 99 Nm | Compression Ratio: 9.5 | Fuel System: Simos 2P) Engine Type 136M (Production: 08.96 ➔ | Displacement: 1.3 l | Power: 50 kW | Torque: 106 Nm | Compression Ratio: 10 | Fuel System: Simos 2P) Common Characteristics (Κοινά χαρακτηριστικά) Bore: 75.5 mm Stroke: 72 mm Firing Order: 1-3-4-2 Ignition Type: Contactless _______________________________________ As for the 136M Compression Ratio, i think is 9.9:1
  8. I have a similar problem with my small cc motorcycle,the rear wheel particularly. Sometimes yes sometimes no,it drives me crazy...
  9. Even by telephone if you say to your mechanic "i listen a Yyyyn" sound when the car rolls in low-mid speed and stops when i brake he will answer "ball bearing". That's the first thing that will do,the sound is characteristic no matter if it's car or motorcycle and there is a specific (funny) slang expression: "this ate it's own bread" which means "his life is finished". Fitting a ball dearing it's a serious task because in case of mistake you need triple work-time to remove it plus the cost,in repair/machine-shops here No newbie employee is allowed to do it. He only carries from the self to the hands of the mechanic,mustn't be dropped down not even thrown to the bench carelessly.
  10. Good news ! English are not my primary language (i am self-taught by books) but can you compare the 2 posts? Is the 2nd the solution as the 1st says?
  11. Double quotation marks and english written almost perfectly which means it's not my text. This was 100% mine: I have paid for ECU programme, i went another time for an update, another time for damaged ECU and install a used, another time to replace that one and install another unit which also paid extra for a whole new programme. Many aftermarket filters and many tries to bring extra fresh-air inside,extra work on the air filter box. Custom exhaust from A to Z,new metallic catalyst converter which i removed after some year and paid for a stock one,extra money for the pipes because from the lambda sensor and after were 3mm wider and not 100% proper bend so i had to replace them (from both of these i lost power in low-medium rpm), extra money for better muffler than the stock (i have changed 3 all these years). Extra money for aftermarket suspension,strut brace,anti-roll bar etc. If i was a guy who wanted a car just to move in a City normally i wouldn't involved in any modification because the cost would be enormous and the gain very small, does not worth the money and the time. My father had a reasoning in his car: «Leave it as is» and compared to me he saved lot of money and had far more quiet days with no worries than me.
  12. Swapping is illegal in the majority of cases in GR. Is not my post and only a blind could see it because i write exclusively based in Greek Grammar-Syntax (by the way these are Greek words) ,i do it in purpose and the text isn't. No logical man will ask AI ''should a take the A medicine or the B from internet for cancer?" or ''should i do heart surgery or leave it as is?" but let my give you a characteristic example: a friend of mine want to install Led bulbs in his 40 years old motorcycle and in forums when asked he read posts from ''i don't know-sigh...first time i hear such a joke-do you really have an old motorcycle and you haven't bought a new as i did? don't do it won't work-ha,ha are you serious?" etc or just nobody replied to him, i suggest him to ask the AI just to get an idea because you can not rely 100% on it in crucial matters. He did it, the AI not only suggest to him a simple modification to do in the harness, the specific type of bulbs that needed and pay attention do not buy other design and some other things for the voltage regulator rectifier that no one told him about when he asked. The result? He got rid off the halogen bulb, installed Led, saved many W from the whole electrical system, can see better and the other drivers pay more attention to him at night. All i did what to give a suggestion from what i have found and let me remind you that few years back we had"The other guy" with an attitude: ''do as i told you-What? you ask for further analysis? i know better i am expert your opinion doesn't count-What? you didn't follow my instructions? so i am not talk to you any more-you are now by your own here". What the gained? He argued with bad manners with 99% of the members,caused nothing more than problems in every topic so now that he is away no one is remember him. @keywacat after all this fuss (which i had the prediction that will be continued) what's your decision? You will buy a cheaper 40Kw engine and then pay to make it 50Kw or you will go straight to 50Kw. PS: from my humble experience you need a lot of money lot of money and time in ECU programming-air filter,new air induction-whole exhaust system to get some HP on Felicia.
  13. That's good news. So according to you worht to buy a cheaper 40Kw engine and then pay to make it 50Kw? I not, the ''AI nonsense" not so let's collect different opinions from members for the best result.
  14. Possible Causes & Diagnostic Steps 1. Bent or Rusted Brake Dust Shield: Why it happens: The metal plate behind the brake disc rusts easily on Felicias. If it is slightly bent or has accumulated rust around its perimeter, it comes into contact with the rotating rotor. When you turn the steering wheel, the microscopic shifting of the wheel causes it to touch or move away. What to do: Jack up the car, remove the wheel, and gently push the shield backward (away from the rotor) using a screwdriver. Clean off any flaking rust that might be rubbing against the disc. 2. CV Joints / Axle: Why it happens: A worn outer CV joint can produce a metallic noise that changes depending on the steering wheel angle. What to do: Inspect the rubber boots for any tears. If the grease has leaked out or water/dirt has gotten inside, the joint dries out and causes friction. 3. Suspension Mounts and Bushings (Control Arm Bushings): Why it happens: If the control arm bushings are worn out ("sagged"), the entire suspension strut shifts under load (e.g., at 60-80 km/h due to aerodynamic pressure and rolling resistance). This alters the alignment of the components, causing friction that disappears as soon as you turn. What to do: Use a pry bar to check for play (looseness) in the control arm bushings and the ball joints. 4. Improperly Seated or Defective New Wheel Bearing: Why it happens: Even though it was replaced, if the bearing was not pressed completely straight (properly seated) into the steering knuckle, the wheel hub may sit at a slight angle. This causes the brake rotor to wobble and rub against the brake pads. This explains why light braking makes the noise disappear.
  15. No need to replace parts with the logic ''if it's not this, it would be the other" etc, this is an money spend situation which never ends. A mechanic can diagnose the wheel bearing when the car is on the lift-jack and turn each wheel by hand.Also turning the steering wheel full left-right and vice versa. Have you ever check or replace the steering wheel fluid? Have you listen with the hood open and the car standing if the noise comes from a pulley? Brake pads whistle when braking, the bent brake discs create vibrations while braking. I had a situation with a grinding-squeaking noise while moving in reverse or when turning in U turns. https://www.briskoda.net/forums/topic/541160-grinding-noise-in-reverse/
  16. ''No, the exhaust assemblies are identical between the 40 kW (135M) and 50 kW (136M) versions. Because both versions share the exact same 1.3L multi-point injection block layout and 8-valve cylinder head shape, they use the same: • Exhaust manifold • Front downpipe and catalytic converter • Middle resonator section • Rear muffler assembly The factory 42mm exhaust bore diameter is more than enough to handle the extra 14 hp from the 136M flat-top pistons''.
  17. For Felicia there is also the BUGIAD BSP21805.
  18. VW Part code 115794220 Febi Bilstein 08883 and as last resort VIKA 88450117101
  19. I think the part's code is 6U0959263A (blower motor resistor) and 6Q0959263A (fan-heat resistance).
  20. You mean this one? 2407.PL - Car Parts Store047103727 VAG - Gasket 047 103 727 - price on 2407.PLGasket VAG 047 103 727 - 21 PLN in online store 2407.pl ✅ Good price ✅ Fast shipping ✅ Hotline 8:00-18:00 It's very cheap, usually is changed after few oil changes and some mechanics (meanwhile) put gasket seal.
  21. Oh No, so i have to move on to 15" wheels and different set of tyres?
  22. Replace it but not with one from Aliexpress although the part code or the picture look OK. Open the ignition switch and spray some Contact Cleaner (No Oil edition).
  23. He found that the grinding noise was coming from the front part of that ''skirt'', every time i was in reverse in an uhill it was touching the pulley producing that horrible noise. Some hammer work from him (yes i know it's cruel but...) and things went back to normal. If a fellow Skodian faces the same problem in the past, now knows where to look.
  24. Before the summer holidays, I had asked the mechanic to inspect the car from under (suspension, rubber boots, potential coolant or oil leaks, etc.). He did so, and (as I’ve mentioned in another thread) he found a loose lower coolant hose and replaced it. I took the car and drove about 200 kilometers to my holiday destination, but one morning, while reversing to pull out of my parking spot, I heard a hair-raising noise (grrrzzzt). I was surprised because I couldn't immediately pinpoint exactly where underneath the vehicle the sound was coming from, and unfortunately, the situation worsened day by day. The steeper the incline when i reversed, the louder the noise became, whereas on flat ground, there was no sound at all ! Unfortunately, there was no repair shop there, so when I returned the next day, i took the car to another mechanic,he put it on the lift, and we both went underneath to see what was going on. The noise was coming from the front right side of the engine,in english may call it ''cover'' but in every day Greek the mechanics call it ''skirt" or ''protective skirt". The photos are lousy because i was sin a hurry but you can get an idea.
  25. 047253041A is the part code. https://www.briskoda.net/forums/topic/524557-felicia-with-heat-shield-in-the-intake-manifold/#findComment-5862650 I have remove it many-many years ago. I have covered the exhaust manifold plus installed a heat shield for the Intake manifold.
