Infotainment Model Numbers

[maxXx]

I have 5E0 035 864A (041) what is it exactly? 😳

[varooom]

22 minutes ago, maxXx said:

I have 5E0 035 864A (041) what is it exactly? 😳

MIB 1 Amundsen

[peraklo]

My data is as follows:



Model: 5Q0035840C

H41

SW: 0456



MST2_EU_SK_ZR_P0456T



I am wondering of the exact model (Amundsen, Bolero, etc)?

I dont have the NAV button.



Also, what can be done on this model, with only SW changes? can navigation be added? voice commands? can i retrofit rear parking camera? Can any kind of wireless Android Auto be fitted?



what about FEC codes, i see some available, like 00040100 (Navigation), 00060300 (MirrorLink) ans some 10 other, that say are supported but not active. Can those be activated, and how?



Thanks for your help.

[varooom]

25 minutes ago, peraklo said:

MST2_EU_SK_ZR_P0456T

You can update to 0480, but don't expect it to magic things to appear.

It cannot add Nav to a unit that does not even have Nav button and all the physical parts missing.

[marouf]

On 06/01/2023 at 10:48, varooom said:

In engineering menu, you can find an update history, unless it was cleared.



Firmware 0480 is by PM, but it would be nice to know the previous firmware stored.

please varoom.

Hi.
i have skoda Octavia III  2019.
Software Version: MST2_EU_SK_ZR_PO472T (0472-1)
Software Base:    H29.319.51-201712011752

when i hold the menu button for a while, "testmode" or Green Engineering Menu
is missing in the hidden menu.
please....... is there any steps to reach "Green Engineering Menu"?
Thanks in advance.


[varooom]

@marouf I have sent link to 0480 version

[Ojosito]

Hola, he actualizado mi MIB2_EU_Sk_P0253,hasta la 367,puse el parche y active el sistema infon, pero no pude activar los swap que tienen instalado, pero no activado, lo intenté muchas veces y nada de nada, descargue la versión 478 y su parche, pero metí por error antes el parche que la actualización, (tengo 2sd card) para no ir dos veces al coche. Ahora la pantalla está bloqueado, el símbolo skoda no se quita, no hay manera de entrar otra vez en el sistema. Ayuda por favor!!!! Gracias por todo.

[PetrolDave]

8 hours ago, Ojosito said:

Hola, he actualizado mi MIB2_EU_Sk_P0253,hasta la 367,puse el parche y active el sistema infon, pero no pude activar los swap que tienen instalado, pero no activado, lo intenté muchas veces y nada de nada, descargue la versión 478 y su parche, pero metí por error antes el parche que la actualización, (tengo 2sd card) para no ir dos veces al coche. Ahora la pantalla está bloqueado, el símbolo skoda no se quita, no hay manera de entrar otra vez en el sistema. Ayuda por favor!!!! Gracias por todo.

We use English here, please post only in English.

[Ojosito]

Tipos de traducción



Texto



Imágenes





Sitios web

Traducción de texto

Detectado: español



swap_horiz



inglés





Texto original







Hola, actualizó mi MIB2_EU_Sk_P0253, ha 367, puse el parche y active el sistema infon, pero no pude activar los swap que tienen instalado, pero no activado, lo intenté muchas veces y nada de nada, descargue la versión 478 y su parche, pero metí por error antes el parche que la actualización, ( tarjeta tengo 2sd ) para no ir dos veces al coche. Ahora la pantalla está bloqueado, el símbolo skoda no se quita, no hay manera de entrar otra vez en el sistema. Ayuda por favor!!!! Gracias por todo.



clear

















495 / 5.000

Resultados de traducción

Resultado de traducción



star_border



Hello, it updated my MIB2_EU_Sk_P0253, it has 367, I put the patch and activate the infon system, but I could not activate the swaps that have installed, but not activated, I tried many times and nothing at all, download version 478 and its patch, but I mistakenly put the patch before the update, (I have a 2sd card) so as not to go to the car twice. Now the screen is locked, the skoda symbol is not removed, there is no way to enter the system again. Please help!!!! Thanks for everything.



[Ojosito]

6 hours ago, PetrolDave said:

We use English here, please post only in English.

OK sorry too much.

Hello, it updated my MIB2_EU_Sk_P0253, it has 367, I put the patch and activate the infon system, but I could not activate the swaps that have installed, but not activated, I tried many times and nothing at all, download version 478 and its patch, but I mistakenly put the patch before the update, (I have a 2sd card) so as not to go to the car twice. Now the screen is locked, the skoda symbol is not removed, there is no way to enter the system again. Please help!!!! Thanks for everything.





•
• Quote



[PetrolDave]

We're drifting off-topic in this thread which is supposed to be about Infotainment MODEL NUMBERS not firmware issues?

[Okey]

Hello everyone,



I am new on this forum and I am from London United Kingdom. I have just bought a 2017 Octavia Mk3.



Please can someone send me a PM with a link for the latest system software update?



My current version is MST2_EU_SK_ZR_P0363T (0363)



Many thanks in advance!



Kind Regards,



Olu.

[ademo]

Hello

I hva octavia 2016

5Q0035840A

H24

0241

MST2_EU_SK_ZR_P0241T(0241)



Can i update ? How to update please

[IgorPin]

Hello,



What is the differece (if there is) between 5Q0035874A and 5Q0035874C?



Can A model run new color menu like C model?



Thanks

[dinko36]

On 14. 07. 2022. at 19:34, varooom said:

Mogu dati link putem PM-a za nekoliko minuta.

U kojoj ste državi? (jer je vatrozid na poslužitelju zaključan preko zemalja)

Please I have the same problem.
Send me the link too

Thank you!!!



[ilhan]

On 12/02/2021 at 12:35, FrankNicklin said:

Hi All



Not sure if this will be of use to anyone, but I have copied this courtesy of Mr-Fix on Youtube.



Below are the current model numbers of the various Infotainment units in the VW group.



Admins please remove if I have duplicated a previous post, but it might be useful to have a pinned post updated as new models are released.





3G0 035 021 - MIB2 VW Discover Pro

3G0 035 043 - MIB2 VW Discover Pro

3G0 035 045 - MIB2 VW Discover Pro

3Q0 035 043 - MIB2 VW Discover Pro



3Q0 035 824 C - MIB2 VW Composition Media

3Q0 035 819 - MIB2 VW Composition Media



3Q0 035 846 - MIB2 VW Discover Media (MQB)

3Q0 035 864 - MIB2.5 VW Discover Media (MQB)

3Q0 035 874 - MIB2 VW Discover Media (MQB)



3V0 035 020 - MIB2 Skoda Columbus

3V0 035 021 - MIB2 Skoda Columbus

3V0 035 043 - MIB2 Skoda Columbus

3V0 035 045 - MIB2 Skoda Columbus

3V0 035 046 - MIB2 Skoda Columbus



5C0 035 680 - MIB2 VW Discover Media (PQ)



5E0 035 020 - MIB1 Skoda Columbus



5G0 035 020 - MIB1 VW Discover Pro (Golf MK7)

5G0 035 043 - MIB1 VW Discover Pro (Golf MK7)



5G0 035 819 - MIB1 VW Composition Media (Golf MK7)

5G0 035 844 - MIB1 VW Composition Media (Golf MK7)



5G0 035 846 - MIB1 VW Discover Media (Golf MK7)

5G0 035 858 - MIB1 VW Discover Media (Golf MK7)

5G0 035 864 - MIB1 VW Discover Media (Golf MK7)



5NA 035 022 - MIB2.5 VW Discover Pro

5NA 035 043 - MIB2.5 VW Discover Pro



5Q0 035 874 - MIB2 Skoda Amundsen

5Q0 035 864 - MIB2 Skoda Amundsen

i have 5e0035 871D = what is it mean D and which MIB should compatible with my device ?

[carsibekir]

Merhaba aracımda bu cihaz mevcut.  5Q0035840B.  Bu ünite Mib2 bolero mu?

[PetrolDave]

On 25/12/2023 at 12:53, carsibekir said:

Merhaba aracımda bu cihaz mevcut.  5Q0035840B.  Bu ünite Mib2 bolero mu?

The language of this forum is English, please at least post an English translation.

[carsibekir]

Merhaba aracımda bu cihaz mevcut. 5Q0035840B. Bu ünite Mib2 bolero mu?



Hello, I am aware of the situation, my English level is a little low, so I'm sorry.  I am writing it with translation to make it as accurate as possible.

[carsibekir]

Hello, I have this device in my vehicle.  5Q0035840B.  Is this unit a Mib2 bolero?

[PetrolDave]

Thank you.

Edited 28 December, 2023 by PetrolDave

[gubbe]

Brand new here and trying to find out what I can update in my Skoda Octavia Mk3. Hoping you guys can help:565 035 021



System information:

Device part number: 565 035 021 D

Hardware : H55 (Columbus 2.5??)

Software: 1382

Navigation Database: V03959806GG0187 ECE 2020/2021

Bluetooth version: 10.754.162

Smartlink: CLU8_SK13ER_065

Radio Database 1.9.7

Media Codec: CLU8_MMX2_SK_ER_G13_065PROD-1



That should be most relevant info.



I've managed to download a map update and radio logos update, but that's it. Still need to update both, so that isn't reflected in the numbers above.



Thanks in advance.



[gubbe]

3 hours ago, gubbe said:

Brand new here and trying to find out what I can update in my Skoda Octavia Mk3. Hoping you guys can help:565 035 021



System information:

Device part number: 565 035 021 D

Hardware : H55 (Columbus 2.5??)

Software: 1382

Navigation Database: V03959806GG0187 ECE 2020/2021

Bluetooth version: 10.754.162

Smartlink: CLU8_SK13ER_065

Radio Database 1.9.7

Media Codec: CLU8_MMX2_SK_ER_G13_065PROD-1



That should be most relevant info.



I've managed to download a map update and radio logos update, but that's it. Still need to update both, so that isn't reflected in the numbers above.



Thanks in advance.





Meanwhile navigation database is at V03959829ML0350 ECE 2024...

[carsibekir]

How can I generate activation for Smartlink?

[Eikka]

Hi,

I have no idea about the model of my infotainment and if there is an update.
