Yes, that looks like the right wire, I expect. Test it for 12V unplugged, as shown in photo

Glad you finally got your MOT. 👍 Check strip fuses in fuseholder above battery, I think ABS will be position no. 4 in your car. Cracking of the metal strip often causes ABS light. Could also be a wheel speed sensor (which point at the inner face of the wheel bearings), but most often it's the strip fuse. All UK market Fabias have ABS as far a I'm aware.

1 2 44 47 51 55 KW MPI Engine | Download Free PDF | Fuel Injection | Belt (Mechanical) (scribd.com)

Isn't that a fuel injector connector, rather than a spark plug/coil connector??

Yes, that sounds like where I'd expect it to be. No idea how easy/difficult access is, sorry.

Next thing then is to check that gets to pin 73 of the black 73-way connector on the BCM. It's a red/yellow wire.

Fuse 8 in the fuseholder under the bonnet is likely to be the problem.

Correct. On your engine it will happen internal to the cylinder head, by valve overlap, rather than via an external device and pipes, I think. No, it's the charge air cooler.

I don't see anything in the parts catalogue to suggest that a DLAC engine has an EGR valve. I think the green ring you've drawn contains a charge air cooler?

What's your engine code, please? Or VIN if you don't know.

I'm confused by your references to EGR valve. I don't think there is any such device on your engine?

Cylinder numbering is correct.

No problem. Ignition coil fuse removed, cranked without starting, obviously. Approx 2 seconds before anything registered on the rpm/tacho dial but then it climbed to a realistic number.

I can (on a 2005 mk1 Fabia HTP/12V) later today, will have to remove a fuse for ignition coils or something, to prevent it starting. Usually start pretty instantly so may not be able to see otherwise.

Lack of rpm indication suggests an electrical problem. Check all fuses for corrosion, one by one.

From VIN, your original front springs are 5Q0411105GN, and rears 3Q0511115AK.

I wonder where the leak is.

That seems like a very high price. What is that quote for, which part(s) and how much labour time?

Part number as per this listing: Skoda Octavia 1Z Alternator Wiring Loom Cables 1K0971230GT (Item #287113) (prestigemotorservices.co.uk) Still available new from Skoda at £58.90 + VAT (so £70.68) I told you ages ago that it doesn't go to the starter motor.

OK, so it's more than one cable wrapped up together, but in the pic with lots of green busted strands, isn't that the thick alternator cable part that's suffered? Anyway, you've got to replace whatever's degraded dramatically there, so add your reg number or VIN, and I can try to find a part number for the sub-loom.

I'd be tempted to look for fuel leaks, for such a dramatic change, but you'd probably see that on the ground, or smell. I'm not really very clued up on diesels/turbo diesels I'm afraid.

I don't understand. The big fat wire from SA1 fuse does go to the alternator output.

It's going to the alternator output stud, surely? Black plastic cover over the nut? Measure how long it is, buy a pre-made 25mm squared cross-section bit of cable with the necessary size crimps on each end. (M8 at alt end, M6 at fuse, maybe?). Must be loads of sellers on ebay selling various or custom lengths with ends to your specifications.

In door, so very likely to be a broken wire in door loom near A-pillar.

Diesels of that era didn't use oxygen sensors, because they always ran with excess air. You may be thinking of petrol engines when you refer to oxygen sensors before and after cats. Latest diesels do have 1 oxygen sensor, but I think only the Common Rail (CR) generation of engines. 1.9 TDIs aren't in that category.
