Hi all,
I had my windscreen replaced some months ago by my local dealer. Everything went well, except... I didn't noticed they had broken (and glued to hide their mistake 🤬) the retainer for park tickets!
Since, I was not able to prove this several months later, I've bought a new one to replace it on my own.
A good opportunity to make a tutorial.
P/N : 3V0 867 333 - 0.72€
First of all, wash your hands before starting to avoid dirty finger prints on the trim panel, especially if you have light grey or 'ivory' interior,
To remove the A-pillar trim panel, use a large and flat lever (a wooden spatula should be ok too ). Insert it on the upper part between the door seal and the trim panel, so that you can push approximately the center part of the panel on the rear side to unclip it:
Then repeat this at middle height of the trim panel to keep on uncliping the trim panel. In red circles below, the 2 clips once the trim panel is uncliped.
Now, you just need to pull the trim panel upward to remove it completely.
Once this is done, if you have a sun roof, start uncliping the water drain hose of the sunroof (red circle), to get a better access to the spreader rivet which fixes the park tickets retainer (both in blue rectangle):
Then you just need to pull the spreader rivet head (if necessary, use a small fork ;)):
Now put the brand new park tickets retainer in place and press the spreader rivet head to fix the retainer.
You can now start reinstalling the A-pillar trim panel. Be sure to engage correctly the lower outer corner in the door seal and the lower inner edge in the dashboard:
Then get out of the car and stand along the A-pillar and adjust the trim panel height, looking thru the windscreen:
Check the lower clip is in front of the slot in the A-pillar. Do the same for the upper clip
Then just press firmly the trim panel, starting with the lower clip. If necessary, don't hesitate: A firm hit with your closed fist 😁!
Press the trim panel at the upper side to completely clip it.
You may then have to make some slight adjustments to get a nice positionning (no bump, no dent under your fingers, when sliding your hand along the trim panel).
Done! 😎
