If there were Briskoda awards for procrastination and lengths of projects I'd like to think I'd be in with a shout?
Anyhow (insert normal excuses here.....) I'm still doing bits and bobs with the car. My not so secret plan with the interior was based around a custom trimmed Cobra Suzuka GT racing seat for the drivers seat only, but trimmed in the OE Fabia vRS material. To cut a long story short I've been dicked about by the trimmer something rotten so that plan has been shelved for now.
However, this does mean that i could do some work on the original drivers seat. Now bear in mind the car is 15 yrs old, had 4 owners and has done 108k miles, the standard drivers seat had held up pretty well. There were no holes, burns or tears, and coupled with the fact that the original owner specified factory fit heated seats and side airbags, meant they are worth looking after.
I could feel the metal rod from inside the bolster foam under the material so it would have only been a matter of time before it would have worn through the cloth and ruined the base material, and i felt this when i bought the car 7 years ago. For once i thought ahead and in 2015 I purchased a new seat foam base from TPS, and it's been stored in the loft ever since ( and been through two house moves!)
The seat foam bases are now no longer available so I dropped lucky at the time in getting one.
Using the excellent guides on here i stripped the base material from the foam, cut the hog rings off and gently eased the heated pad off as well. Quite surprising how bad the foam was when uncovered...
The new foam was then offered up
I gently glued the heated pad back in place at the front and back edge and then set about the tricky task of securing the fabric back over the now very firm foam with the hog rings and hog ring pliers. There is certainly a knack to doing it but once I had worked that out it went ok.
I secured the seat fabric back round the edges of the seat frame and built the seat back up using new plastics on the bases, again sourced recently from TPS.
The finished construction of the seat base is now complete and the original fabric is now stretched tightly over the firm foam base, exactly how the seats were new.
Please be aware that the seat itself is now due a deep wet valet, where all of the dirty marks will be removed, this is just to show you how the base looks with new foam :-)
I'm currently repainting the seat runners so when they are refitted and the seat has been deep cleaned I'll present the finished article.
