The new front coilovers are AP mk1 Focus units, as I mentioned previously. For top mounts I bought some CompBrake adjustable solid parts. The only part of the front struts which was reused was the top spring cap. These do not look like standard Caddy (Felicia) parts, and nor do they resemble the parts that came with the coilovers, so I have no idea what they were originally designed for, but they are perfect for what I need. The FK front coilovers had been pressed into the hub carriers with considerable force, and there was no way they could be removed. Because of this I had to source some replacement hub carriers, which I had machined to accommodate the new coilovers and the larger mounting bolts for my Ford (ATE) callipers. When they came back from the machine shop I gave them a lick of paint before trial fitting the assembled front struts. Anti-roll bar and drop-link bushes had been sourced from Superflex months back, but when I tried them against the ARB I realised it is 20mm diameter, not 22mm as I had thought. The 20mm bushes took a couple of weeks to arrive from Poland, but when they did the package contained a note apologising for the delay, and a small pack of Haribo. I will be happy to order from them again. New wishbones were fitted, and went on a treat with new bolts after the damaged captive thread had been re-tapped. The ARB drop-link bushes and drop-link mounting bushes are actually the same as mk2 Ibiza parts, although the Ibiza drop-link is straight whereas the Caddy part is inclined. In this photo the plastic bag is protecting the new track rod ball joint while waiting for rack gaiters to arrive. I had always planned to replace the track rod ends, but they were seized solid so I had to buy new track rods too. I do not know why, but Felicia / Caddy front wheel bearings seem to be my kryptonite. Whenever I try to replace them, however careful I am to follow the correct methodology, I always end-up with the bearing inner race stuck resolutely to the hub, and the outer race similarly in the hub carrier. There were some fraught moments, including a big circlip that should have been secure deciding it was no such thing, but eventually I had new bearings and hubs fitted to freshly machined hub carriers. Before assembling these onto the Caddy I removed the top mounts, which I bolted loosely into place first. I then offered the uprights into position so I could feed the driveshafts through the hubs, and put the top nuts on, at which point the weight of the uprights was supported and I could pop them onto the bottom ball-joints. I will probably replace the top mount bolts with longer bolts fed through from under the top mount plate, so that it is easier to remove the strut brace without having to worry about the top mount being detached at the same time. New track rod ends were fitted, and everything was torqued-up, with a jack under the ball-joint to make sure the damper was properly located in the hub carrier. Both the strut and ball-joint pinch bolts were replaced with new. The brake callipers are now looking a bit shabby in comparison to the shiny new suspension parts. A brakes refurb may be on the agenda shortly. The strut pinch bolt had not been tightened when this photo was taken.
