Going away in a few weeks all going well, same as last year. Since I won't have the power I want, I want to do everything to minimise power loss.
My biggest problem last year in the summer heat, was heat soak. I've since put a front mount on, but I figured I could do more in the form of an intercooler sprayer.
I could buy a kit ofcourse, but that costs money and there's no way really to mount it stealthily.
So then I thought about plumbing into the washer bottle, but I couldn't figure out a good way of splitting the feed on the fly to the intercooler.
So, I had a look and noticed the mk1 has the bottle on the passengers side. Whereas the mk2 has it on the drivers side.
After a bit of looking. I noticed the top bolt is in the same spot, and there's a hole near the power steering reservoir on the mk2 where the bottle also mounts to. Good enough.
Hoped to just remove the splash panel and snake it up through there, which proved optimistic. Had to loosen the bumper off and pop the headlight out to get the best access.
And with a bit of fettling, it fits. Looks standard, if a bit odd. It's a pretty tight fit, but the splash panel and fog do go back in properly. This is only a 2l bottle, I seriously doubt a 5l fits.
Even used the nozzles from a mk1, fit pretty well, tied on top of the bumper spraying down.
Wired it with a relay, fused of course. Then used one of those fuse taps inside on the fuse for the wipers (switched ignition), and put a push switch through that to turn it on and off. It's taped into place for now near the radio, until I can find a good spot for it.
Works well for a parts bin bodge job. Think I'll add some isopropyl alcohol to it, which is meant to cool things even more.
I'll need to add some sort of return valve to the washer hosing as it drips down if the bottles too full. But happy thus far.
20230523_214406.mp4
